Description
Curved bridge assembly 42.9 × 26.3 mm, height 22 mm, six Φ5.5 holes on 28 mm spacing.
Hardware part specs
- Overall width 42.9 mm (1.689 in)
- Overall length 26.3 mm (1.035 in)
- Body height 22 mm (0.866 in)
- Overall height 22 mm (0.866 in)
- Hole diameter φ5.5 mm
- Mount spacing 28 mm (1.102 in)
- Reference 6×Φ5.5; front spacing 19.9 mm; rear Φ8; string holes 33.9 / 20.4 mm; radius R118.6
Hardware
- Material Zinc alloy / steel (per part)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Radiused bridge plate (R118.6)
About measurements
- Mount hole spacing
-
28 mm (1.102 in)
Center-to-center distance between mounting holes on the bridge plate.
